MWMIK JACKAL

The Mobility Weapon-Mounted Installation Kit (MWMIK), or 'Jackal', is an open armoured vehicle used by The Royal Marines and Parachute Regiment, as well as other UK forces in Afghanistan. The Jackal can be used as a reconnaissance / long range patrol vehicle as well as a fire support platform. It has been of particular use to light recce units such as 3 Commando Brigade's Brigade Patrol Troop and 16 Air Assault's Pathfinder Platoon, largely replacing the lighter, less capable Land Rover WMIK. With thicker tires and better ground clearance, the Jackal offer greatly improved off-road handling. Side armour provides better protection from small arms fire than the WMIK. It is also claimed that the Supacat offers greater protection from IEDs. Whilst this may be true with regards to mines exploded underneath the vehicle, the Supacat MWMIK's occupants are still vulnerable to blast damage from roadside bombs.

The Jackal has a crew of 3. A typical loadout for a Jackal comprises of a GPMG, HMG .50 cal machine gun, or HK GMG 40mm grenade launcher as its main weapon, complemented by a GPMG mounted at the vehicle commander's station.

mwmik Jackal
MWMIK Jackal pictured at Camp Bastion, Afghanistan, 2008
image by Cpl Ian Houlding  | © UK MOD / Crown Copyright 2014
Used under Open Government Licence


UKSF units such as the SAS, SBS and SFSG use the Supacat HTM 400, an almost identical vehicle to the Jackal, configured for Special Forces operations.

Supacat HMT400 / JACKAL Specifications

Engine Cummins 6-cylinder 5.9-litre turbo-charged diesel engine
Max Power 134 Kw (185 BPH) @2500 RPM
Max Torque 650 Nm @ 1500 rpm
Transmission Allison 2500 automatic 5-speed
Maximum speed 80 kph on mettled road
Wheels 20 in x 10 Alloy one-piece drop well rims or run flat rim system
Weight
Axle 1 3500kg
Axle 2 3500kg
UW 4700kg
GVW 7000kg
Tyres Michelin 335/80R20 XML MPT TL 141 K
Fuel System
Main Tank 147 litre
Aux Tank 50 litre
Features: Power Steering
Adjustable steering column
Twin shock absorbers on per wheel station

Jackal 2

In 2009, the MoD announced that an upgraded MWMIK, the 'Jackal 2' was to be introduced into service. At least 110 Jackal 2s have reportedly been ordered. Changes include:

Jackal 2
A Jackal 2 speeds across terrain.
image by Cpl Ian Forsyth RLC  | © UK MOD / Crown Copyright 2009
Used under Open Government Licence

Coyote TSV

coyote tsv
A Coyote tactical support vehicle (TSV) - a 6x6 vehicle that features increased cargo space and is designed to carry supplies and equipment in support of the Jackal 2. It is based on the HMT 600 6x6 chassis and is crewed by 4.
image by Andrew Linnett  | © UK MOD / Crown Copyright 2014
Used under Open Government Licence
